Chemical & Environmental Total Engineering Solution
Under the slogan "German Process Engineering & Local Execution," TY delivers turnkey engineering solutions for
highly complex chemical processes and environmental systems through technical alliances with global technology
leaders.
Beyond simple equipment supply, our comprehensive EPC capabilities—spanning basic/detail engineering,
fabrication, installation, commissioning, and after-sales service—maximize process efficiency and support clients in
achieving ESG and carbon neutrality goals.
MVR Evaporation & Crystallization System (Advanced ZLD Solution)
"Challenging Zero Liquid Discharge via High-Concentration Brine Valorization"
ZLD System
Zero Liquid Discharge
80% Energy Saving
In technical partnership with EBNER GmbH (Germany). Applies highefficiency Mechanical Vapor Recompression (MVR) to reuse 100% latent heat, cutting energy costs by 80% compared to onventional steam
High-Purity Salt
EBNER's proprietary DTB/FC crystallizers generate coarse crystals, directly recovering high-purity salt with only 3~5% moisture without requiring extra dryers
95%+ Water Reuse
Recovers over 80~90% of wastewater as ultra-high purity condensate for immediate process reuse, drastically reducing plant water utility costs
Applications
Battery materials (Precursor/Cathode) wastewater, semiconductor highsalinity brine, power plant FGD wastewater, and chemical brine processing
Next-Gen Sulfuric Acid Concentration & Purification System (ExtrAcid®)
"Transforming Process Waste Heat into High-Pressure Steam Revenue"
ExtrAcid®
Acid Purification
10ppt Ultra-Purity
In partnership with Wilk-Graphite. A 3-stage integrated process (MVR → MEE → C1 Purification) produces 10ppt electronic-grade ultra-high purity sulfuric acid
Zero Corrosion
Utilizes NoMoCorr® SSiC (Sintered Silicon Carbide) block heat exchangers, ensuring zero corrosion and semi-permanent lifespan even in boiling, highly concentrated acid
71% OPEX Reduction
Recovers exothermic reaction heat as up to 15 bar high-pressure steam for process reuse or monetization. Skid-mounted ground installation eliminates tower vibration and ensures safety
High-Efficiency Stripper & Organic Solvent Recycling System
"Regenerating Waste Stripper to Virgin Quality via Circular Clean Technology"
Stripper Recycle
Solvent Regeneration
99.5%+ Purity
Refines waste stripper from LCD and semiconductor manufacturing to achieve virgin-like quality with >99.5% purity and >85% recovery yield
Low-Temp Distillation
Low-temperature, high-vacuum operation minimizes thermal degradation. Multi-stage packing columns precisely separate complex compounds with close boiling points
Smart Auto-Blending
Real-time concentration analyzers integrated with auto-blending units maintain exact chemical ratios for instant recirculation → Reduces chemical purchasing & waste costs while earning ESG certifications
Alkali Recovery & Specialty Chemical Purification Systems
"Extracting Valuable Resources from Diverse Industrial Waste Streams"
Alkali Recovery
Resource Valorization
Tailored Engineering
Customized evaporation, crystallization, and filtration processes designed specifically around the chemical properties of incoming industrial waste streams
Total Anti-Corrosion
Integrates TY's core technologies in glass lining, special alloys, and Teflon coatings to ensure flawless, continuous operation in severe strong-acid and strong-alkali environments
Integrated EPC Capabilities (Why TY Pfaudler?)
The perfect synergy of German core technology and local direct execution ensures project success from design to maintenance.
Basic & Detail Engineering
Specialized process design including P&ID, 3D plant modeling, and precise Heat & Mass Balance optimization
Manufacturing & Procurement
Direct in-house fabrication of core equipment and steel structures, backed by global procurement networks.
Installation & CS Support
Skilled on-site erection, commissioning, and rapid customized emergency maintenance (CS) support for local clients
